TIMBRE bookshelf speaker exploded along the depth of the cabinet: walnut shell anchored, woofer and tweeter pulled toward the viewer, hand-built crossover revealed to the side, bass-reflex port lifted clear at the rear

Explain No. 05

Timbre

Bookshelf speaker, exploded along cabinet depth

Spread, Tweeter to Port

548 mm

Weight, Not Watts

01 Tweeter — dome, brass bezel 02 Woofer — cone, copper dustcap 03 Crossover — hand-built coil 04 Cabinet — walnut shell 05 Port — lifted clear

Macro detail of the hand-built crossover: a wound air-core copper coil and a film capacitor beside the walnut cabinet wall and a brass driver trim ring

Detail — Crossover

The one part with no source asset: a coil wound by hand, two capacitors, built to split the signal

Plate

Driver
2-way, dome + cone
Crossover
Air coil, 2 caps
Cabinet
Walnut, lacquered
Hardware
Brass, copper
Axis
Single, cabinet depth
Spread
548 mm
